Permanent Sintered Alnico Magnets Alnico 5 Magnet For Guitar Pickups
  • name
  • name
  • name
  • name
  • name

Permanent Sintered Alnico Magnets Alnico 5 Magnet For Guitar Pickups

MOQ: 100pcs
Price: As negotiation
Standard Packaging: cartons,pallets
Delivery Period: 20-25days
Payment Method: T/T L/C
Supply Capacity: 20 tons per month for SmCo magnet
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
UNMAG
Magnetization Direction:
Axial, Radial, Multi-poles...
Grade:
Alnico 5,8 Is Normally Used
Type:
Permanent Magnet
Max Operating Temperature:
550℃
Application:
Generator, Microphone, Measuring Instrument
BHmax:
1.13-9 MGOe
Hcj:
≥30 KA/m
Tolerance:
±0.05mm
Highlight:

Permanent Sintered Alnico Magnets

,

Alnico 5 Magnet For Guitar Pickups

Product Description
Permanent Sintered Alnico Magnets Alnico 5 Magnet For Guitar Pickups
Product Specifications
Attribute Value
Magnetization Direction Axial, Radial, Multi-poles
Grade Alnico 5,8 Is Normally Used
Type Permanent Magnet
Max Operating Temperature 550℃
Application Generator, Microphone, Measuring Instrument
BHmax 1.13-9 MGOe
Hcj ≥30 KA/m
Tolerance ±0.05mm
Product Description
Sintered Alnico magnets are permanent magnets made of cast Alnico material, ideal for guitar pickups and various industrial applications. These high-performance magnets offer outstanding magnetic force with coercivity up to 30KA/m, available in axial, radial, and multi-pole configurations.
Key Features
  • High magnetic strength with excellent stability
  • Available in Alnico 5 and Alnico 8 grades
  • Precision tolerance of ±0.05mm
  • Maximum operating temperature of 550℃
  • Long-lasting magnetic retention
  • Multiple magnetization directions available
Technical Parameters
Grade Equivalent MMPA Class Remanence Intrinsic Coercivity Coercivity Maximum Energy Product Density g/cm3 Reversible Temp. Coefficient %/℃ Curie Temp. ℃ Temp.Coefficient ℃ Remark
Br mT Gs Hcj KA/m Oe Hcb KA/m Oe (BH)max KJ/m3 MGOe
FLN8 Alnico3 520 5200 43 540 40 500 8-10 1.0-1.25 6.8 -0.02 760 450 Isotropic
Applications
These high-grade Alnico magnets are widely used in generators, microphones, measuring instruments, and other precision applications requiring stable magnetic performance. Their precise magnetization direction (axial, radial, or multi-pole) makes them particularly suitable for specialized industrial uses.
Customization Options
We offer custom-made Alnico permanent magnets tailored to your specific requirements. Our standard delivery time is 25-30 days after order confirmation, with precision tolerance of ±0.05mm and BHmax ranging from 1.13-9 MGOe.
Packaging & Shipping
All magnets are securely packaged in wooden or plastic boxes with protective bubble wrap to prevent damage during transit. Each package is accurately labeled with weight and dimensions to ensure safe and timely delivery via reputable courier services.
UNMAG Brand Advantage: As a leading manufacturer of high-quality Alnico permanent magnets, we provide superior magnetic products with precise tolerances and consistent performance. Our Alnico 5 and Alnico 8 magnets deliver exceptional magnetic properties for demanding industrial applications.
