OEM ODM Lightweight Cast Alnico Magnet Excellent Performance
  • name
  • name
  • name
  • name
  • name

OEM ODM Lightweight Cast Alnico Magnet Excellent Performance

MOQ: 100pcs
Price: As negotiation
Standard Packaging: cartons,pallets
Delivery Period: 20-25days
Payment Method: T/T L/C
Supply Capacity: 20 tons per month for SmCo magnet
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
UNMAG
Grade:
Alnico 5,8 Is Normally Used
Magnetization Direction:
Axial, Radial, Multi-poles...
Hcj:
≥30 KA/m
Material:
Cast Alnico
Max Operating Temperature:
550℃
Tolerance:
±0.05mm
BHmax:
1.13-9 MGOe
Application:
Generator, Microphone, Measuring Instrument
Highlight:

Lightweight Cast Alnico Magnet

,

OEM Alnico Permanent Magnet

,

OEM Cast Alnico Magnet

Product Description
OEM ODM Lightweight Cast Alnico Magnet Excellent Performance
Product Specifications
Attribute Value
Grade Alnico 5,8 Is Normally Used
Magnetization Direction Axial, Radial, Multi-poles...
Hcj ≥30 KA/m
Material Cast Alnico
Max Operating Temperature 550℃
Tolerance ±0.05mm
BHmax 1.13-9 MGOe
Application Generator, Microphone, Measuring Instrument
Product Description
Alnico Permanent Magnet is a high-performance cast Alnico magnet known for its exceptional magnetic properties and durability. With a coercivity (Hcj) of ≥30 KA/m and magnetic energy product (BHmax) ranging from 1.13-9 MGOe, it delivers reliable performance in demanding applications.
Key Features
  • High coercivity: ≥30 KA/m
  • Excellent magnetic energy product: 1.13-9 MGOe
  • Precision dimensional tolerance: ±0.05mm
  • High temperature resistance: up to 550℃
  • Available in multiple magnetization directions (axial, radial, multi-poles)
  • Standard grades: Alnico 5 and Alnico 8
Technical Parameters
Grade Equivalent MMPA Class Remanence Br Intrinsic Coercivity Hcj Coercivity Hcb Maximum Energy Product (BH)max Density g/cm3 Reversible Temp. Coefficient α(Br) Curie Temp. TC Temp.Coefficient TW Remark
FLN8 Alnico3 520 mT (5200 Gs) 43 KA/m (540 Oe) 40 KA/m (500 Oe) 8-10 KJ/m3 (1.0-1.25 MGOe) 6.8 -0.02 %/℃ 760 ℃ 450 ℃ Isotropic
Applications
Our Alnico Permanent Magnets are widely used in precision applications including:
  • Generators
  • Microphones
  • Measuring instruments
  • Other industrial applications requiring stable magnetic performance
Customization & Delivery
We offer custom-made Alnico Permanent Magnets tailored to your specific requirements. Standard delivery time is 25-30 days with guaranteed dimensional tolerance of ±0.05mm.
Packaging & Shipping
All magnets are securely packaged in cardboard boxes with protective bubble wrap or foam to prevent damage during transit. Each shipment is clearly labeled and sealed for safe transportation.
