Alnico 8 Industrial Rare Earth Alnico Magnet High Coercive Force Permanent
  • name
  • name
  • name
  • name
  • name

Alnico 8 Industrial Rare Earth Alnico Magnet High Coercive Force Permanent

MOQ: 100pcs
Price: As negotiation
Standard Packaging: cartons,pallets
Delivery Period: 20-25days
Payment Method: T/T L/C
Supply Capacity: 20 tons per month for SmCo magnet
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
UNMAG
Type:
Permanent Magnet
Tolerance:
±0.05mm
Magnetization Direction:
Axial, Radial, Multi-poles...
BHmax:
1.13-9 MGOe
Application:
Generator, Microphone, Measuring Instrument
Max Operating Temperature:
550℃
Grade:
Alnico 5,8 Is Normally Used
Hcj:
≥30 KA/m
Highlight:

Permanent Alnico 8 Magnet

,

Industrial Alnico 8 Magnet

Product Description
Alnico 8 Industrial Rare Earth Alnico Magnet High Coercive Force Permanent
Key Specifications
Attribute Value
Type Permanent Magnet
Tolerance ±0.05mm
Magnetization Direction Axial, Radial, Multi-poles
BHmax 1.13-9 MGOe
Application Generator, Microphone, Measuring Instrument
Max Operating Temperature 550℃
Grade Alnico 5,8 Is Normally Used
Hcj ≥30 KA/m
Product Overview
Alnico Permanent Magnet is a high-performance permanent magnet material with excellent temperature stability and magnetic properties. Available in various grades including Alnico 5, 8, 8M, and 9, these magnets feature high BHmax values (1.13-9 MGOe) and can be magnetized in multiple directions (axial, radial, multi-pole).
Technical Features
  • Exceptional temperature stability for high heat applications
  • Maximum working temperature range: 450-550°C
  • High residual induction and energy product compared to ceramic materials
  • Low coercive force compared to ceramic and rare earth materials
  • Most commonly used grades: Alnico 5 and 8
  • Not suitable for repelling or high friction applications
Physical Properties
Parameter Value
Curie Temperature 760 ~ 890℃
Max. Operating Temperature 450 ~ 550℃
Resistivity 47 ~ 54 μΩ·cm
Hardness 520 ~ 630 HV
Density 6.9 ~ 7.3 g/cm³
Relative Recoil Permeability 1.7 ~ 4.7 μrec
Saturation Field Strength 2.7 ~ 6.3 kOe / 215~500 kA/m
Temperature Coefficient of Br -0.025 ~ -0.02%/℃
Temperature Coefficient of iHc +0.01 ~ +0.03 %/℃
Applications
Ideal for demanding applications including generators, motors, microphones, measuring instruments, loudspeakers, and sensors. Particularly suited for environments requiring stable performance under high temperatures.
Customization & Shipping
Brand: UNMAG
Origin: China
Delivery Time: 25-30 days
Material: Cast Alnico
Custom Options: Available in various shapes and sizes including rods, bars, and specialized configurations
Magnets are securely packaged in protective cardboard boxes with bubble wrap lining, sealed with strong adhesive tape, and shipped on pallets with secure strapping.
