Corrosion Resistance Alnico 8 Magnet Cast Sintered Permanent
  • name
  • name
  • name

Corrosion Resistance Alnico 8 Magnet Cast Sintered Permanent

MOQ: 100pcs
Price: As negotiation
Standard Packaging: cartons,pallets
Delivery Period: 20-25days
Payment Method: T/T L/C
Supply Capacity: 20 tons per month for SmCo magnet
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
UNMAG
Application:
Generator, Microphone, Measuring Instrument
Magnetization Direction:
Axial, Radial, Multi-poles..
Tolerance:
±0.05mm
Max Operating Temperature:
550℃
Size:
Customized
BHmax:
1.13-9 MGOe
Shape:
Customized
Material:
Alnico
Highlight:

Corrosion Resistance Alnico 8 Magnet

,

Sintered Alnico 8 Magnet

,

Corrosion Resistance Alnico Permanent Magnet

Product Description
Corrosion Resistance Alnico 8 Magnet Cast Sintered Permanent
Product Attributes
Attribute Value
Application Generator, Microphone, Measuring Instrument
Magnetization Direction Axial, Radial, Multi-poles
Tolerance ±0.05mm
Max Operating Temperature 550℃
Size Customized
BHmax 1.13-9 MGOe
Shape Customized
Material Alnico
Product Description

Alnico Rod Magnet is a high-performance permanent magnet made from an alloy of aluminum, nickel, and cobalt. These magnets offer exceptional temperature stability, superior corrosion resistance, and high magnetic strength, with precision tolerances up to ±0.05mm.

Key Features
  • Available in customized shapes and sizes
  • Multiple magnetization directions (axial, radial, multi-poles)
  • Excellent temperature stability for high heat applications
  • High residual induction and energy product
  • Wide operating temperature range (up to 550℃)
Technical Specifications
Parameter Name Value
Cruie Temperature 760 ~ 890℃
Max. Operating Temperature 450 ~ 550℃
Resistivity 47 ~ 54 μ Ω.cm
Hardness 520 ~ 630 HV
Density 6.9 ~ 7.3 g/cm³
Relative Recoil Permeability 1.7 ~ 4.7 μrec
Saturation Field Strength 2.7 ~ 6.3 kOe / 215~500 kA/m
Temperature Coefficient of Br -0.025 ~ -0.02%/℃
Temperature Coefficient of iHc +0.01 ~ +0.03 %/℃
Applications

Alnico 8 magnets are widely used in demanding industrial applications including:

  • Generators and motors
  • Precision measuring instruments
  • Microphones and audio equipment
  • Automotive components
  • Medical devices
  • Electronics and instrumentation
Customization Options

Our Alnico 8 magnets can be customized to meet your exact specifications:

  • Custom shapes and sizes
  • Precision tolerances (±0.05mm)
  • Various magnetization directions
  • Branding: UNMAG
  • Origin: China
  • Specification: LNG37 Cast Alnico Magnet
Support & Services

We provide comprehensive support for our Alnico permanent magnets:

  • 24/7 technical support
  • Product advice and troubleshooting
  • Installation guidance
  • Product testing and evaluation
Packaging & Shipping

Our flexible packaging solutions ensure safe delivery:

  • Bulk packaging in boxes/cartons
  • Individual packaging options (plastic bags, blister packs, small boxes)
  • Multiple shipping methods (regular mail, freight, air shipping)
Tags:

alnico permanent magnet,

permanent magnet alnico,

alnico rod magnets
