IATF16949 Sintered Neodymium Magnet Multi Polar For Traction Motors

MOQ:	100pcs
Price:	As negotiation
Standard Packaging:	cartons,pallets
Delivery Period:	20-25days
Payment Method:	T/T L/C
Supply Capacity:	100 tons per month for NdFeB magnet

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

UNMAG

Certification

ISO9001, IATF16949, ISO14001

Shape:

Customized

Grade:

N35-N52

Application:

New Energy Cars,Wind Power Generation,Servo Motors,Traction Motors

Corrosion Resistance:

High

Magnetic Flux Density:

High

Pull Force:

High

Highlight:

Sintered Neodymium Magnet IATF

Sintered Neodymium Magnet Multi Polar

Product Description

IATF16949 Sintered Neodymium Magnet Multi Polar For Traction Motors

Product Overview

Sintered neodymium magnet is a high performance magnet made of rare earth material and magnetic alloy compound. Certified to IATF16949 standards, these multi-polar magnets are specifically designed for traction motors in new energy vehicles, offering superior magnetic properties and corrosion resistance.

Key Specifications

Attribute	Value
Shape	Customized
Grade	N35-N52
Applications	New Energy Cars, Wind Power Generation, Servo Motors, Traction Motors
Corrosion Resistance	High
Magnetic Flux Density	High
Pull Force	High

Technical Parameters

Physical Properties

Parameter Name	Parameter Values	Unit
Curie Temperature	310～380	℃
Relative Recoil Permeability	1.02～1.05
Reversible Temperature Coefficient of Br (20~100℃)	-0.09～-0.13	%/℃
Reversible Temperature Coefficient of Hcj (20~100℃)	-0.4～-0.7	%/℃
Density	7.50～7.70	g/cm3
Vickers Hardness	550～700
Compressive Strength	800 ~1050	MPa

Maximum Working Temperatures

Grade Series	Working Temperature (℃)
NSeries (N35~N52)	≤80
MSeries (38M~50M)	≤100
HSeries (35H~48H)	≤120
SHSeries (33SH~48SH)	≤150

Tolerance Control

Dimension Type	Range (mm)	Tolerance (mm)
Wall Thickness	T≤10	±0.04
Wall Thickness	10<T≤30	±0.05
Length	L≤10	±0.04
Length	10<L≤30	±0.05

Available size range: L≤200mm, W≤100mm, T: 1.5~50mm, H3~60mm

Customization & Applications

UNMAG Sintered Neodymium Magnets provide the perfect solution for new energy cars, wind power generation, servo motors, and traction motors. Our magnets are crafted using powder metallurgy technology, offering superior magnetic properties and corrosion resistance.

We provide fully customized sintered neodymium magnets with:

High pull force and magnetic field strength
Excellent temperature resistance
Multiple coating options (Nickel, Zinc, Epoxy)
Certified to ISO9001, IATF16949, and ISO14001 standards

Support & Services

Our comprehensive technical support includes:

Installation assistance
Technical training and documentation
24/7 troubleshooting support
Product configuration and optimization
