PRODUCTS DETAILS

Home > Products >

20kg Pull Force BN-6 Bonded Neodymium Magnet

Products

Rubber Coated Magnet

sales@unmagnet.com

86-592-5130661

Contact Now

20kg Pull Force BN-6 Bonded Neodymium Magnet

MOQ:	100pcs
Price:	As negotiation
Standard Packaging:	cartons,pallets
Delivery Period:	20-25days
Payment Method:	T/T L/C
Supply Capacity:	100 tons per month for NdFeB magnet

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

UNMAG

Product Name:

Bonded Neodymium Magnet

Max Operating Temperature:

120°C

Shape:

Disc, Block, Cylinder, Ring, Etc.

Pull Force:

Up To 20kg

Grade:

BN-6,BN-8,BN-10...

Application:

Spinder Motor,Stepping Motor,Synchronous Motor,DC Motor, Brushless Motor Etc

Size:

Customized

MOQ:

100 Pieces

Highlight:

BN6 Bonded Neodymium Magnet

20kg Bonded Neodymium Magnet

Product Description

20kg Pull Force BN-6 Bonded Neodymium Magnet

Product Overview

Bonded Neodymium Magnets are injection bonded magnets made from NdFeB Alloy Powder with a tolerance of ±0.05mm. Available with epoxy or parylene coatings in grades BN-6 to BN-10, these high-performance magnets are ideal for motor applications and industrial uses.

Key Specifications

Attribute	Value
Product Name	Bonded Neodymium Magnet
Max Operating Temperature	120°C
Available Shapes	Disc, Block, Cylinder, Ring, etc.
Pull Force	Up to 20kg
Grades Available	BN-6, BN-8, BN-10...
Applications	Spindle Motor, Stepping Motor, Synchronous Motor, DC Motor, Brushless Motor
Size Options	Customized
Minimum Order Quantity	100 Pieces

Technical Parameters

Physical Properties

Parameter Name	Unit	Value
Density	g/cm³	4.0-6.5
Curie Temperature	℃	300-350
Recoil Permeability	μrec	1.2
Temperature Coefficient	%/℃	-0.17
Hardness	Hv	80-120
Resistivity	Ω.cm	0.026
Compressive Strength	kgf/mm²	3
Flexural Strength	kg/mm²	25
Thermal Expansivity	10-6/℃	1-2

Manufacturing Process

Mixing

Melting and quenching

Coarse pulverization

Resin mixing

Forming

Hardening

Surface treatment (coating)

Magnetization

Applications

Industrial motors (spindle, stepping, synchronous, DC, brushless)
Generators and medical devices
Speakers and audio equipment
Refrigerator magnets and office applications
Multi-pole configurations for specialized uses

Customization Options

UNMAG offers custom bonded neodymium magnets in various shapes, grades, and sizes to meet specific application requirements. Our magnets can be tailored for axial, radial, and multiple-pole configurations.

Packaging & Shipping

Packed in corrugated boxes or pallets
Individual plastic bag protection
Secure tape sealing
Temperature-controlled shipping available
Reliable tracking and insurance options

Our technical team is available to assist with your specific requirements and provide expert guidance for your application needs.
