8 Pole Bonded Neodymium Magnet Neodymium Ring Magnet For Spinder Motor
  • name
  • name
  • name

8 Pole Bonded Neodymium Magnet Neodymium Ring Magnet For Spinder Motor

MOQ: 100pcs
Price: As negotiation
Standard Packaging: cartons,pallets
Delivery Period: 20-25days
Payment Method: T/T L/C
Supply Capacity: 100 tons per month for NdFeB magnet
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
UNMAG
Size:
Customized
Grade:
BN-6,BN-8,BN-10..
MOQ:
100 Pieces
Pull Force:
Up To 20kg
Coating:
Epoxy,Parylene
Application:
Spinder Motor,Stepping Motor,Synchronous Motor,DC Motor, Brushless Motor Etc
Tolerance:
+/-0.05mm
Material:
NdFeB Alloy Powder
Highlight:

8 Pole Neodymium Ring Magnet

,

Spinder Motor Neodymium Ring Magnet

,

8 Pole Bonded Neodymium Magnet

Product Description
8 Pole Bonded Neodymium Magnet Neodymium Ring Magnet For Spinder Motor
Product Specifications
Attribute Value
Size Customized
Grade BN-6, BN-8, BN-10..
MOQ 100 Pieces
Pull Force Up To 20kg
Coating Epoxy, Parylene
Application Spinder Motor, Stepping Motor, Synchronous Motor, DC Motor, Brushless Motor etc.
Tolerance +/-0.05mm
Material NdFeB Alloy Powder
Product Description

Bonded neodymium magnet is a permanent magnetic material made from neodymium iron boron alloy powder and adhesive. With excellent magnetic properties, these magnets are widely used in spinder motors, stepping motors, synchronous motors, DC motors, and brushless motors.

Key Features:
  • Available in various shapes: disc, block, cylinder, ring
  • Can be magnetized in axial, radial, or multi-poles direction
  • Maximum operating temperature: 120°C without losing magnetic properties
  • High coercivity and wide working temperature range
  • Superior corrosion resistance and temperature stability
  • Strong adhesive force for easy bonding to other materials

Our bonded neodymium magnets offer excellent performance at competitive prices. We provide customization options for size, shape, thickness, color, finish, and coating to meet specific requirements.

Technical Specifications
Physical Properties:
Parameter Name Unit Value
Density g/cm³ 4.0-6.5
Curie Temperature ℃ 300-350
Recoil Permeability μrec 1.2
Temperature Coefficient %/℃ -0.17
Hardness Hv 80-120
Resistivity Ω.cm 0.026
Compressive Strength kgf/mm² 3
Flexural Strength kg/mm² 25
Thermal Expansivity 10-6/℃ 1-2
Applications

These injection bonded magnets provide superior longevity and enhanced performance for various applications including:

  • Electric motors
  • Loudspeakers
  • Magnetic separators
  • Sensors
  • Pumps
  • Medical equipment
Customization Options
Brand:

UNMAG

Place of Origin:

China

Available Grades:

BN-6, BN-8, BN-10..

Keywords:
Bonded NdFeB Magnets Neodymium Magnet Ring 8 Pole Bonded Arched NdFeB Magnet
Support & Services

We provide full technical support with experienced engineers available to answer questions. On-site installation and repair services are available when needed.

Packaging & Shipping

Products are individually shrink-wrapped and packaged in corrugated or custom printed boxes. Shipping options include:

  • UPS or FedEx for domestic shipments
  • DHL for international shipments

All shipments are tracked and insured.

Tags:

bonded ndfeb magnets,

ndfeb ring magnet,

radial neodymium magnets
