High Performance Smco Permanent Magnets Uncoated YXG-32 Customized
  • name
  • name
  • name
  • name
  • name

High Performance Smco Permanent Magnets Uncoated YXG-32 Customized

MOQ: 100pcs
Price: As negotiation
Standard Packaging: cartons,pallets
Delivery Period: 20-25days
Payment Method: T/T L/C
Supply Capacity: 20 tons per month for SmCo magnet
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
UNMAG
Operating Temperature:
250-500°C
Magnetization:
Through Axial,Thickness Or Customized
Grade:
YXG-26H, YXG-30H, YXG-28, YXG-30, YXG-32
Material:
Samarium Cobalt
Coating:
Uncoated
Application:
Spaceflight,National Defense,Microwave,Sensors
Highlight:

Smco Permanent Magnets YXG-32

,

Customized Smco Permanent Magnets

,

Uncoated samarium cobalt permanent magnets

Product Description
High Performance SmCo Permanent Magnets Uncoated YXG-32 Customized
Product Specifications
Operating Temperature:
250-500°C
Magnetization:
Through Axial, Thickness or Customized
Grade:
YXG-26H, YXG-30H, YXG-28, YXG-30, YXG-32
Material:
Samarium Cobalt
Coating:
Uncoated
Application:
Spaceflight, National Defense, Microwave, Sensors
Product Description

Samarium Cobalt (SmCo) magnets are high-performance permanent magnets made from Samarium Cobalt material, designed for applications requiring exceptional magnetic flux density and high-temperature operation. Available in multiple grades including YXG-26H, YXG-30H, YXG-28, YXG-30, and YXG-32, these uncoated magnets offer superior temperature stability with an operating range of 250-500°C.

Key Features
  • Excellent temperature stability (250-500°C operating range)
  • Available in multiple grades for different performance requirements
  • Customizable magnetization (axial, thickness, or custom configurations)
  • Available in various forms including rings, discs, blocks, and cylinders
  • Ideal for demanding applications in aerospace, defense, and industrial sectors
Technical Specifications
Grade Remanence (Br) Coercivity (Hcb) Intrinsic Coercivity (Hcj) Max Energy Product (BH)max Curie Temperature (TC) Max Work Temp (TW)
YXG-24H 0.95-1.02 T 692-764 kA/m ≥1990 kA/m 175-191 kJ/m³ 800°C 350°C
YXG-26H 1.02-1.05 T 748-796 kA/m ≥1990 kA/m 191-207 kJ/m³ 800°C 350°C
YXG-28H 1.03-1.08 T 756-812 kA/m ≥1990 kA/m 207-220 kJ/m³ 800°C 350°C
YXG-30H 1.08-1.10 T 788-835 kA/m ≥1990 kA/m 220-240 kJ/m³ 800°C 350°C
YXG-32H 1.10-1.13 T 812-860 kA/m ≥1990 kA/m 230-255 kJ/m³ 800°C 350°C
Applications

Our SmCo magnets are engineered for high-performance applications in:

  • Aerospace and spaceflight systems
  • National defense and military equipment
  • Microwave technology
  • Precision sensors and instrumentation
  • High-temperature industrial applications
Customization Options

We offer fully customizable SmCo magnets to meet your specific requirements:

  • Custom sizes and shapes (rings, discs, blocks, cylinders)
  • Tailored magnetization patterns
  • Specialized grades for specific performance characteristics
  • Custom packaging solutions
Packaging & Shipping

All SmCo magnets are carefully packaged in high-quality, moisture-proof containers with protective foam lining to ensure safe arrival. We offer multiple shipping options including ground, expedited, and international delivery. Shipping costs are calculated based on product weight and destination.

Tags:

samarium cobalt rare earth magnets,

samarium cobalt ring magnets,

samarium cobalt bar magnets
