Neodymium Multi Pole Magnet With NdFeB Alloy Powder And Parylene

MOQ:	100pcs
Price:	As negotiation
Standard Packaging:	cartons,pallets
Delivery Period:	20-25days
Payment Method:	T/T L/C
Supply Capacity:	100 tons per month for NdFeB magnet

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

UNMAG

Material:

NdFeB Alloy Powder

Application:

Spinder Motor,Stepping Motor,Synchronous Motor,DC Motor, Brushless Motor Etc

Size:

Customized

Product Name:

Bonded Neodymium Magnet

Grade:

BN-6,BN-8,BN-10..

Tolerance:

+/-0.05mm

Pull Force:

Up To 20kg

Shape:

Disc, Block, Cylinder, Ring, Etc.

Highlight:

Neodymium Multi Pole Magnet

NdFeB Alloy Powder Multi Pole Magnet

Product Description

Neodymium Multi Pole Magnet With NdFeB Alloy Powder And Parylene

Product Overview

Our Bonded Neodymium Magnet is a high-performance permanent magnet composed of neodymium, iron, and boron (NdFeB). It features exceptional magnetic strength with an extremely high maximum energy product, available in various grades (BN-6, BN-8, BN-10, etc.) to meet diverse performance requirements.

Key Specifications

Attribute	Value
Material	NdFeB Alloy Powder
Applications	Spindle Motor, Stepping Motor, Synchronous Motor, DC Motor, Brushless Motor
Size	Customized
Grade	BN-6, BN-8, BN-10, etc.
Tolerance	±0.05mm
Pull Force	Up to 20kg
Shapes	Disc, Block, Cylinder, Ring, etc.

Technical Specifications

Physical Properties

Parameter	Unit	Value
Density	g/cm³	4.0-6.5
Curie Temperature	℃	300-350
Recoil Permeability	μrec	1.2
Temperature Coefficient	%/℃	-0.17
Hardness	Hv	80-120

Magnetic Characteristics

Grade	Remanence (Br)	Coercivity (Hcb)	Max Energy Product (BH max)
BN-6	500-600 mT	320-400 KA/m	52-60 KJ/m³
BN-8	630-680 mT	400-480 KA/m	68-76 KJ/m³
BN-10	680-730 mT	400-480 KA/m	76-84 KJ/m³

Applications

Motor systems (spindle, stepping, synchronous, DC, brushless)

Magnetic assemblies and sensors

Robotics and automation equipment

Medical and aerospace applications

Automotive components

Consumer products and industrial equipment

Customization Options

Custom shapes (disc, block, cylinder, ring, etc.)

Various magnetization directions (axial, radial, multi-poles)

Tailored sizes to meet specific requirements

Special configurations (bonded arched NdFeB, 8-pole rings)

Minimum order quantity: 100 pieces
Standard tolerance: ±0.05mm
Packaging: Carton box or pallet

Support & Services

Our technical support team provides comprehensive assistance with product selection, installation, and troubleshooting. We offer 24/7 support via phone, email, or chat, along with detailed technical documentation and product training resources.
